B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 369 -

5280

Position control loop gain for the spindle and tapping axis in rigid tapping

(common to all gears)

5281

Position control loop gain for the spindle and tapping axis in rigid tapping

(first-stage gear)

5282

Position control loop gain for the spindle and tapping axis in rigid tapping

(second-stage gear)

5283

Position control loop gain for the spindle and tapping axis in rigid tapping

(third-stage gear)

Position control loop gain for the spindle and tapping axis in rigid tapping

(fourth-stage gear)

5284

[Data type] Word

[Unit of data] 0.01 s

-1

[Valid data range] 1 to 9999

Each of these parameters is used to set a position control loop gain for

the spindle and tapping axis in rigid tapping. These parameters

significantly affect the precision of threading. By conducting a cutting

test, make a tuning to obtain an optimal value.

When performing threading with an analog spindle, tune the loop gain

multipliers (parameter No. 5291 to No. 5294) as well.

NOTE

1 When these parameters are set, the power must be

turned off before operation is continued.

2 To use a varied loop gain on a gear-by-gear basis,

set parameter No. 5280 to 0, and set a loop gain for

each gear in parameters No. 5281 through No.

5284. The specification of a loop gain on a

gear-by-gear basis is disabled if parameter No. 5280

is set to a value other than 0. In such a case, the

value set in parameter No. 5280 is used as a loop

gain that is common to all the gears.

3 When rigid tapping is performed using the second

and third spindles

• When bit 1 (SPR) of parameter No. 5204 is set to

0, the setting of parameter No. 5280 or the

settings of parameters No. 5281 and No. 5282

are applied to the second and third spindles, as

well as to the first spindle.

• When bit 1 (SPR) of parameter No. 5204 is set to

1, the settings of parameters No. 5341 through

No. 5343 are applied to the second spindle, while

the settings of parameters No. 5344 through No.

5346 are applied to the third spindle.
