B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 289 -

P code for selecting the first spindle in multi-spindle control

3781

P code for selecting the second spindle in multi-spindle control

3782

P code for selecting the third spindle in multi-spindle control

3783

P code for selecting the fourth spindle in multi-spindle control

3784

NOTE

When these parameters are set, the power must be

turned off before operation is continued.

[Data type] Word

[Valid data range] 0, 1 to 32767

If bit 3 (MPP) of parameter No. 3703 is set to 1, set the P code to

select each spindle under multi-spindle control. Specify the P code in

a block containing the S command.

[Example] If the P code value for selecting the second spindle is set to 3,

S1000 P3;

causes the second spindle to rotate at S1000.

NOTE

1 These parameters are valid if bit 3 (MPP) of

parameter No. 3703 is set to 1.

2 If this parameter is set to 0, the corresponding

spindle cannot be selected by a P code.

3 Under multi-path control, the P code specified here

is valid for each path.

For instance, if the P code to select the first spindle

of path 2 is set to 21, specifying S1000 P21; in path

1 causes the first spindle of path 2 to be rotated at

S1000.

4 Identical P code values cannot be used for different

spindles. (Identical P code values cannot be used

even if the paths are different.)

5 If this parameter is used (bit 3 (MPP) of parameter

No. 3703 is set to 1), signals SWS1 to SWS4

<G027#0 to #2, G026#3> and SLSPA/SLSPB

<G063#2 and #3> become invalid.

6 To use this parameter, the multi-spindle control

function is needed.

7 Parameter No. 3784 is valid only for Series

16i/160i/160is.
