B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 145 -

1821 Reference counter size for each axis

NOTE

When this parameter is set, the power must be

turned off before operation is continued.

[Data type] 2-word axis

[Unit of data] Detection unit

[Valid data range] 0 to 99999999

Set the size of the reference counter.

When using an encoder with absolute address reference marks (linear

scale/rotary encoder), set the interval of mark 1 of the encoder with

absolute address reference marks (linear scale/rotary encoder).

NOTE

When a scale with distance-coded reference marks

(detection circuit C) is used, this parameter is used

for an ordinary purpose (reference counter size for

each axis).

1825 Servo loop gain for each axis

[Data type] Word axis

[Unit of data] 0.01 s

-1

[Valid data range] 1 to 9999

Set the loop gain for position control for each axis.

When the machine performs linear and circular interpolation (cutting),

the same value must be set for all axes. When the machine requires

positioning only, the values set for the axes may differ from one

another. As the loop gain increases, the response by position control is

improved. A too large loop gain, however, makes the servo system

unstable.

The relationship between the positioning deviation (the number of

pulses counted by the error counter) and the feedrate is expressed as

follows:

Feedrate

Positioning deviation =

60 × (loop gain)

Unit :

Positioning deviation : mm, inches, or deg

Feedrate : mm/min, inches/min, or deg/min

loop gain : s

-1
