4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 140 -

SCRx To set rotary axis B type for a rotary axis that uses a scale with no

speed data, speed data conversion is:

0 : Not performed.

1 : Performed.

NOTE

1 This parameter is valid only for an axis of rotary

axis B type.

2 Do not set this parameter even for an axis of rotary

axis B type if no discontinuity point in scale data

exists within the movable range of the rotary axis.

3 If the setting of this parameter is modified, perform

a reference position establishment operation again.

4 With the T series, this parameter is valid only for a

rotary encoder with distance-coded reference

marks (detection circuit C).

SCPx When bit 2 (DC2) of parameter No. 1802 is set to 1, the encoder

origin of an encoder with absolute address reference marks (linear

scale/rotary encoder) is:

0 : Placed on the minus side.

(The reference position is placed in the plus direction when

viewed from the encoder origin.)

1 : Placed on the plus side.

(The reference position is placed in the minus direction when

viewed from the encoder origin.)

NOTE

1 If this parameter is set to an incorrect value, a

coordinate system is established incorrectly. In

such a case, reverse the setting then perform a

reference position establishment operation again.

2 When an encoder with distance-coded reference

marks (linear scale/rotary encoder) (detection

circuit C) is used, the setting of this parameter is

invalid.

TANx Tandem control

0 : Not used

1 : Used

NOTE

Set this parameter to both master axis and slave

axis.
