Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 623

Parameter manual
B-63530EN/03 4.DESCRIPTION OF PARAMETERS
- 611 -
#7 #6 #5 #4 #3 #2 #1 #0
8700 DMM
[Data type] Bit
DMM In DNC operation from the PMC, OPEN CNC, or C-EXE, pre-reading
is:
0 : Not performed.
1 : Performed.
#7 #6 #5 #4 #3 #2 #1 #0
CTV WPR
8701
WPR
[Data type] Bit
WPR The function that allows parameters that are rewritten using the PMC
window to be enabled during automatic operation is:
0 : Disabled.
1 : Enabled.
NOTE
If this parameter is set, a move command based on
manual operation is disabled (interlock state) while
parameter rewriting using the PMC window is being
executed.
CTV When Symbol CAPi T is provided, 1 must be specified.
#7 #6 #5 #4 #3 #2 #1 #0
8702 LFM SME
[Data type] Bit
SME During DNC operation or M198 calling, parameter No. 8790 (timing
for executing an auxiliary macro) is:
0 : Invalid.
1 : Valid.
LFM At the beginning of program uploading in response to a request using
the data window library:
0 : "LF+%" is not output.
1 : "LF+%" is output.
