B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 271 -

PCS When two or three paths are used and multi-spindle control is

exercised on each path, the selection of the feedback signal of the

position coder in a selected path, regardless of the state of the

PC2SLC signal (G0028#7, G1028#7, G2028#7) of the selected path,

is:

0 : Impossible.

1 : Possible. (When three paths are used, the position coder of a path

is selected with signals below:

SLPCA

<G0064#2>, SLPCA

<G1064#2>,

SLPCA

<G2064#2>, SLPCB

<G0064#3>,

SLPCB

<G1064#3>, SLPCB

<G2064#3>)

On a 3-path lathe, a position coder feedback signal selection can be

made as indicated in the table below. (The "-" mark indicates

irrelevancy to PC selection on the path side.)

<1> When the bit 3 (PCS) of Parameter No.3706 is set to 1.

Position coder to

be selected

SLPCA

SLPCB

PC2SLC

PC1

1 0 0 - -

PC2

1 0 1 - -

PC1

0 1 0 - -

PC2

0 1 1 - -

PC1

1 1 0 - -

Path

PC2

1 1 1 - -

Position coder to

be selected

SLPCA

SLPCB

PC2SLC

PC1

1 0 - 0 -

PC2

1 0 - 1 -

PC1

0 1 - 0 -

PC2

0 1 - 1 -

PC1

1 1 - 0 -

Path

PC2

1 1 - 1 -

Position coder to

be selected

SLPCA

SLPCB

PC2SLC

PC1

1 0 - - 0

PC2

1 0 - - 1

PC1

0 1 - - 0

PC2

0 1 - - 1

PC1

1 1 - - 0

Path

PC2

1 1 - - 1
