B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 463 -

#7 #6 #5 #4 #3 #2 #1 #0

T99

6802

RMT TSK TGN ARL GRP E17 TCO T99

[Data type] Bit

T99 If a tool group whose life has expired is found to exist when M99 is

executed in the main program:

0 : The tool change signal is not output.

1 : The tool change signal is output.

TCO When function code 171 or 172 (tool life management data write) of

the PMC window function is specified, tool data of a tool in the

currently selected group that is currently not in use:

0 : Cannot be cleared.

1 : Can be cleared.

E17 When function code 171 or 172 (tool life management data write) of

the PMC window function is specified to clear tool life management

data of the tool currently in use in the currently selected group:

0 : The tool data is not cleared and operation terminates normally.

1 : The tool data is not cleared and completion code 13 is output.

GRP As management data for the tool life arrival notice signal TLCHB

<F064#3> :

0 : Parameters Nos. 6844 and 6845 are used.

1 : The value set for each group with the extended tool life

management function is used.

By setting the remaining life until new tool selection for each group,

the signal TLCHB <F064#3> is output when the value obtained by

subtracting the tool use count (COUNT) from the life setting (LIFE)

reaches the value (remaining life) set for each group.

NOTE

This parameter is valid only when tool life

management B is used.

ARL The tool life arrival notice signal TLCHB <F064#3> of tool life

management is:

0 : Output for each tool.

1 : Output for the last tool in a group.

This parameter is valid only when bit 3 (GRP) of parameter No. 6802

is set to 1.

TGN In tool life management B, the arbitrary group number set function is:

0 : Not used.

1 : Used.

TSK When the life is specified by time and the last tool in a group is

skipped in tool life management:

0 : The count for the last tool indicates the life value.

1 : The count for the last tool is not changed.
