B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 451 -

#7 #6 #5 #4 #3 #2 #1 #0

CSR

6501

CSR FIM RID 3PL TLC ORG

[Data type] Bit

ORG Movement when coordinate system is altered during drawing

0 : Draws in the same coordinate system

1 : Draws in the new coordinate system (only for the tool path

drawing)

TLC In solid drawing

0 : Not compensate the tool length

1 : Compensates the tool length

3PL In solid drawing, a three-view drawing is created:

0 : In third angle projection

1 : In first angle projection

RID In solid drawing

0 : Draws a plane without edges.

1 : Draws a plane with edges.

FIM Machining profile drawing in solid drawing

0 : Displayed in the coarse mode

1 : Displayed in the fine mode

CSR While the screen image is enlarged, the shape of the graphic cursor is:

0 : A square. (

)

1 : An X. (X)

#7 #6 #5 #4 #3 #2 #1 #0

CYG

6503

MST

[Data type] Bit

MST In check drawing (animated simulation) using the dynamic graphic

display function, the M, S, and T code commands in the program are:

0 : Ignored.

1 : Output to the machine in the same way as in normal operation.

CYG CY-axis drawing coordinate system setting

0 : The CY-axis animated simulation coordinate system is not set.

1 : The CY-axis animated simulation coordinate system is set.

When this parameter is set to "1", parameter No. 6510 is invalid.

When bit 1 (SPC) of parameter No. 6500 is set to "1", this parameter

is invalid.
