4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 196 -

#7 #6 #5 #4 #3 #2 #1 #0

SPN HNG ITA CHI FRN GRM JPN

3102

DTH SPN HNG ITA CHI FRN GRM JPN

#7 #6 #5 #4 #3 #2 #1 #0

3119 POR

#7 #6 #5 #4 #3 #2 #1 #0

3190 CZE SWE HUN POL

NOTE

When these parameters are set, the power must be

turned off before operation is continued.

[Data type] Bit

Select the language to be used for the display.

RUS CH2 CZE SWE HUN POL POR DTH SPN HNG ITA CHI FRN GRM JPN Language

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

English

0 0 0 0 0 0 0 0 0 0 0 0 0 0 1

Japanese

0 0 0 0 0 0 0 0 0 0 0 0 0 1 0

German

0 0 0 0 0 0 0 0 0 0 0 0 1 0 0

French

0 0 0 0 0 0 0 0 0 0 0 1 0 0 0

Chinese

(traditional character)

0 0 0 0 0 0 0 0 0 0 1 0 0 0 0

Italian

0 0 0 0 0 0 0 0 0 1 0 0 0 0 0

Korean

0 0 0 0 0 0 0 0 1 0 0 0 0 0 0

Spanish

0 0 0 0 0 0 0 1 0 0 0 0 0 0 0

Dutch

0 0 0 0 0 0 1 0 0 0 0 0 0 0 0

Portuguese

0 0 0 0 0 1 0 0 0 0 0 0 0 0 0

Polish

0 0 0 0 1 0 0 0 0 0 0 0 0 0 0

Hungarian

0 0 0 1 0 0 0 0 0 0 0 0 0 0 0

Swedish

0 0 1 0 0 0 0 0 0 0 0 0 0 0 0

Czech

0 1 0 0 0 0 0 0 0 0 0 0 0 0 0

Chinese

(simplified character)

1 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Russian

#7 #6 #5 #4 #3 #2 #1 #0

ABR NMH DIP

3103

NMH

[Data type] Bit

D1P When two-path control is applied, the current position display screen

displays:

0 : The current positions of the two paths regardless of the tool post

select signal.

1 : The current position of a path selected by the tool post select

signal.

NOTE

Set this parameter when using the seven-soft key

type display unit.
