Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 234

Parameter manual
4.DESCRIPTION OF PARAMETERS B-63530EN/03
- 222 -
PSR Search for the program number of a protected program
0 : Disabled
1 : Enabled
NOTE
If this parameter is set, a protected program is also
displayed.
#7 #6 #5 #4 #3 #2 #1 #0
MCL MER MZE PIO
3203
MCL MER MZE
[Data type] Bit
PIO When two-path control is controlled, program input/output is:
0 : Controlled separately for each tool post.
1 : Controlled on a two-path control basis for path 1 and path 2.
MZE After MDI operation is started, program editing during operation is:
0 : Enabled
1 : Disabled
MER When the last block of a program has been executed at single block
operation in the MDI mode, the executed block is:
0 : Not deleted
1 : Deleted
NOTE
When MER is set to 0, the program is deleted if the
end-of-record mark (%) is read and executed. (The
mark % is automatically inserted at the end of a
program.)
MCL Whether a program prepared in the MDI mode is cleared by reset
0 : Not deleted
1 : deleted
#7 #6 #5 #4 #3 #2 #1 #0
3204 MKP SPR P9E P8E EXK PAR
[Data type] Bit
PAR When a small keyboard is used, characters "[" and "]" are:
0 : Used as "[" and "]".
1 : Used as "(" and ")".
