Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 413

Parameter manual

Page of 782

/ 782

B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 401 -

4.34 PARAMETERS OF EXPONENTIAL INTERPOLATION

#7 #6 #5 #4 #3 #2 #1 #0

5630

SPN

[Data type] Bit

SPN The amount of linear axis division (span value) in exponential

interpolation is:

0 : Specified with parameter No. 5643.

1 : Specified using address K in a block containing G02.3/G03.3.

When address K is not specified, the value set with parameter No.

5643 is used.

5641

Linear axis number subject to exponential interpolation

[Data type] Byte

[Valid data range] 1 to number of controlled axes

This parameter sets the ordinal number, among the controlled axes, for

the linear axis to which exponential interpolation is applied.

5642

Rotary axis number subject exponential interpolation

[Data type] Byte

[Valid data range] 1 to number of controlled axes

This parameter sets the ordinal number, among the controlled axes, for

the rotary axis to which exponential interpolation is applied.

5643

Amount of linear axis division (span value) in exponential interpolation

[Data type] 2-word

[Valid data range]

Input increment IS-A IS-B IS-C Unit

Metric input 0.01 0.001 0.0001 mm

Inch input 0.001 0.0001 0.00001 inch

[Valid data range] 1 to 99999999

This parameter sets the amount of linear axis division in exponential

interpolation when bit 0 (SPN) of parameter No.5630 is set to 0.
