4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 68 -

4.14 PARAMETERS OF STORED STROKE CHECK

#7 #6 #5 #4 #3 #2 #1 #0

1300 BFA LZR RL3 LMS NAL OUT

[Data type] Bit

OUT The area inside or outside of the stored stroke check 2 is set as an

inhibition area (setting by the parameters No.1322 and No.1323).

0 : Inside

1 : Outside

NAL Specifies whether to issue an alarm related to stored stroke check 1, as

follows:

0 : To issue an alarm.

1 : Not to issue an alarm; the stroke limit reached signal <F124> or

<F126> is output (for a manual operation).

LMS The EXLM <G007#6> signal for switching stored stroke check

0 : Disabled

1 : Enabled

NOTE

Stored stroke check 1 supports two pairs of

parameters for setting the prohibited area. The

stored stroke limit switching signal is used to

enable either of the prohibited areas set with these

parameter pairs.

(1) Prohibited area I:

Parameters No.1320 and No.1321

(2) Prohibited area II:

Parameters No.1326 and No.1327

RL3 Stored stroke check 3 release signal RLSOT3 <G007#4> is

0 : Disabled

1 : Enabled

LZR Checking of stored stroke check 1 during the time from power-on to

the manual reference position return

0 : The stroke check 1 is checked.

1 : The stroke check 1 is not checked

NOTE

When an absolute position detector is used and a

reference position is already set upon power-up,

stored stroke limit check 1 is started immediately

after power-up, regardless of the setting.
