4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 584 -

8376

Chopping compensation scaling factor

[Data type] Byte

[Unit of data] %

[Valid data range] 0 to 100

This parameter specifies a scaling factor used to multiply the

compensation value for a servo delay or acceleration/deceleration

delay in an chopping operation. When this parameter is set to 0, servo

delay compensation will not be applied.

8377

Compensation start tolerance

[Data type] Word

[Unit of data]

Input increment IS-A IS-B IS-C Unit

Metric machine 0.01 0.001 0.0001 mm

Inch machine 0.001 0.0001 0.00001 inch

Rotary axis 0.01 0.001 0.0001 deg

[Valid data range] 0 to 32767

Compensation is applied when the difference between an amount of

shortage at the upper dead point and that at the lower dead point is less

than the value specified in this parameter. In other words, this

parameter is used to enable compensation after the chopping operation

settles. When the parameter is set to 0, compensation will not be

applied.

8378

Amount of an error permissible for starting increase in speed

[Data type] 2-word

[Unit of data]

Input increment IS-A IS-B IS-C Unit

Metric input 0.01 0.001 0.0001 mm

Inch input 0.001 0.0001 0.00001 inch

Rotary axis 0.001 0.0001 0.00001 deg

[Valid data range] 0 to 99999999

This parameter sets the amount of an error permissible for starting

increase in speed.

When the amount of shortage at the lower dead point becomes smaller

than the value set in this parameter, clamping at the maximum

chopping feedrate is not performed.
