Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 472

Parameter manual
4.DESCRIPTION OF PARAMETERS B-63530EN/03
- 460 -
6757 Operation time (integrated value of one automatic operation time) I
This parameter can also be set on the “Setting screen”.
[Data type] 2-word
[Unit of data] msec
[Valid data range] 0 to 60000
6758 Operation time (integrated value of one automatic operation time) II
This parameter can also be set on the “Setting screen”.
[Data type] 2-word
[Unit of data] min
[Valid data range] 0 to 99999999
This parameter displays the one automatic operation drive time
(neither stop nor hold state included). The actual time accumulated
during operating is the sum of parameter No. 6757 and No. 6758. The
operation time is automatically preset to 0 during the power-on
sequence and the cycle start from the reset state.
