B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 499 -

7510

Maximum allowable number of simultaneous axes when G05 is specified for

high-speed cycle machining, maximum allowable number of axes controlled

by the high-speed remote buffer, or maximum allowable number of axes

controlled in the high-precision/AI high-precision/AI nano high-precision

contour control/five-axis machining function mode

[Data type] Word

[Valid data range] 1, 2, 3 to number of controlled axes

This parameter sets the maximum allowable number of simultaneous

axes when G05 is specified for high-speed cycle machining, the

maximum allowable number of axes controlled by the high-speed

remote buffer, or the maximum allowable number of axes controlled

in the high-precision/AI high-precision/AI nano high-precision

contour control/five-axis machining function mode.

[Example] When the axes consists of the X-axis, Z-axis, C-axis, Y-axis, and

A-axis in this order, and AI high-precision/AI nano high-precision

contour control is to be enabled for the fourth axis (Y), 4 is to be set in

this parameter. In this case, AI high-precision/AI nano high-precision

contour control is enabled also for the X-axis, Z-axis, and C-axis.

X-axis, Z-axis, C-axis, Y-axis:

Axes for which AI high-precision/AI nano high-precision

contour control is enabled

A-axis:

AI high-precision/AI nano high-precision contour control is

disabled.

NOTE

When exercising simple synchronous control (M

series) in the AI high-precision contour control, AI

nano high-precision contour control, or five-axis

machining function mode, set a value considering

the slave axes for simple synchronous control. (For

high-precision contour control, slave axes need not

be considered.)

7514

Retract direction and retract feedrate in high-speed cycle machining retract

operation

[Data type] 2-word axis

[Unit of data, valid data range]

Valid data range

Input increment Units of data

IS-A, IS-B IS-C

Metric machine 1 mm/min

-30 to -240000

30 to 240000

-30 to -100000

30 to 100000

Inch machine 0.1 inch/min

-30 to -96000

30 to 96000

-30 to -48000

30 to 48000

This parameter sets a retract direction and retract feedrate along each

axis in a high-speed cycle machining retract operation. The retract

direction is specified by a sign.
