Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 722

Parameter manual
4.DESCRIPTION OF PARAMETERS B-63530EN/03
- 710 -
4.97 PARAMETERS OF AI/AI-NANO HIGH-PRECISION
CONTOUR CONTROL AND FUNCTIONS RELATED FOR
RISC PROCESSOR OPERATION
#7 #6 #5 #4 #3 #2 #1 #0
19500 FNW
[Data type] Bit
FNW When the feedrate is determined according to the feedrate difference
and acceleration in AI/AI-nano high-precision contour control:
0 : The maximum feedrate at which the allowable feedrate
difference and acceleration for each axis are not exceeded is
used.
1 : The maximum feedrate at which the allowable feedrate
difference and acceleration for each axis are not exceeded is used.
The feedrate is determined so that the decreased feedrate is
constant regardless of the move direction when the profile is the
same.
When this parameter is set to 1, the feedrate decreased by feedrate
determination according to the feedrate difference and acceleration is
reduced by up to about 30% as compared with the feedrate determined
when the parameter is set to 0.
