4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 512 -

Master axis in polygon machining with two spindles

7640

Polygon synchronous axis in polygon machining with two spindles

7641

[Data type] Byte

[Valid data range] 0, 1 to number of spindles, or

m × 10 + n (m:1 to number of paths, n:1 to number of spindles)

These parameters set the master and polygon synchronous (slave) axes

in polygon machining with two spindles.

[Settings] 1 to 4 : First to fourth serial spindles of the local path

11 to 14 : First to fourth serial spindles of path 1

21 to 24 : First to fourth serial spindles of path 2

31 to 32 : First to second serial spindles of path 3

NOTE

1 Polygon machining option with two spindles is

enabled only for serial spindles.

2 When any one of parameters No. 7640 and No.

7641 is set to 0, polygon turning is performed using

the first spindle (master axis) and the second

spindle (polygon synchronous axis) in the path to

which the parameter belongs.

3 When one of the second to fourth serial spindles is

used as a master axis, and the S command is to be

used for the master axis, the multi-spindle control

option is required.

4 When the PMC window function or G10 command

is used to rewrite this parameter, rewrite this

parameter before the block specifying the polygon

machining command G51.2 (G251) with two

spindles. When the PMC window function is used

to rewrite this parameter in the block immediately

before G51.2 (G251), specify the rewriting of this

parameter by using an M code (parameters No.

3411 to No. 3420) without buffering.
