4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 534 -

8021 Minimum speed of rapid traverse override in axis control by PMC (Fo)

[Data type] Word axis

[Unit of data, valid data range]

Valid data range

Input increment Units of data

IS-B IS-C

Metric machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotary axis 1 deg/min 6 to 15000 6 to 12000

This parameter sets the minimum speed (Fo) of rapid traverse override

on axis control by PMC.

8022 Upper-limit rate of feed per revolution in axis control by PMC

[Data type] Word

[Unit of data, valid data range]

Valid data range

Input increment Units of data

IS-B IS-C

Metric machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotary axis 1 deg/min 6 to 15000 6 to 12000

This parameter sets the upper limit rate of feed per revolution on axis

control by PMC.

NOTE

The upper limit specified for the first axis is valid for

all axes. The specifications for the second and

subsequent axes are ignored.

8028

Linear acceleration/deceleration time constant for speed commands for axis

control by PMC

[Data type] Word axis

[Unit of data] msec/1000 min

-1

[Valid data range] 0 to 32767

This parameter sets the time required for the servo motor rotation

speed to increase or decrease by 1000 min

-1

, for each axis, as a linear

acceleration/deceleration time constant for speed commands for axis

control by PMC. (See the description of bit 6 (JVB) of parameter No.

8003 as well.)

NOTE

If this parameter is set to 0,

acceleration/deceleration control is not applied.
