/ 782

4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 206 -

ICS When the

CUSTOM

(using standard MDI unit) function key is pressed

while the custom screen is being displayed:

0 : The screen is changed.

1 : The screen is not changed.

#7 #6 #5 #4 #3 #2 #1 #0

APLx NDFx SFMx NDAx NDPx

3115

D10x APLx NDFx NDAx NDPx

[Data type] Bit axis

NDPx Display of the current position for each axis

0 : The current position is displayed.

1 : The current position is not displayed.

NOTE

When using the electric gear box (EGB) function,

set 1 for the EGB dummy axis to disable current

position display.

NDAx Position display using absolute coordinates and relative coordinates is:

0 : Performed.

1 : Not performed. (Machine coordinates are displayed.)

SFMx In current position display, subscripts are:

0 : Added to the absolute, relative, and machine coordinate axis

names.

1 : Assed only to the machine coordinate axis names.

NOTE

This parameter is disabled in the two-path control

system.

NDFx To the actual speed display, axis movement data is:

0 : Added.

1 : Not added.

NOTE

Even if bit 1 (PCF) of parameter No.3105 is set to

0, so as to add PMC controlled axis movement

data to the actual speed display, the movement

data for a PMC controlled axis for which NDFx is

set to 1 is not added to the actual speed display.
