Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 626

Parameter manual
4.DESCRIPTION OF PARAMETERS B-63530EN/03
- 614 -
#7 #6 #5 #4 #3 #2 #1 #0
8706 NWD HSD
NOTE
When at least one of these parameters is set, the
power must be turned off before operation is
continued.
[Data type] Bit
HSD Main machining during DNC operation with FOCAS1/HSSB is:
0 : Normal operation.
1 : High-speed operation.
Set this parameter according to machining during DNC operation.
Usually, when binary operation and programs containing contiguous
small blocks are performed during DNC operation with
FOCAS1/HSSB, high-speed operation is selected.
NOTE
For details of this parameter, also refer to "FANUC
Open CNC DNC Operation Management Package
OPERATOR’S MANUAL" and other manuals.
NWD During DNC operation with FOCAS1/HSSB, new DNC functions are:
0 : Not executed.
1 : Executed.
When this parameter is set, the M198 command (subprogram call) can
also be executed with FOCAS1/HSSB.
NOTE
To execute the M198 command with
FOCAS1/HSSB, parameter No. 20 must be set to
"15".
For details of this parameter, also refer to "FANUC
Open CNC DNC Operation Management Package
OPERATOR’S MANUAL" and other manuals.
