4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 156 -

1883

Distance 1 from the mark origin of an encoder with absolute addressing

reference marks/encoder with distance-coded reference marks (detection

circuit C) to the reference position

NOTE

When this parameter is set, the power must be

turned off before operation is continued.

[Data type] 2-word axis

[Unit of data] Detection unit

[Valid data range] -99999999 to 99999999

1884

Distance 2 from the mark origin of an encoder with absolute addressing

reference marks/encoder with distance-coded reference marks (detection

circuit C) to the reference position

NOTE

1 When this parameter is set, the power must be

turned off before operation is continued.

2 If a value not within the valid data range is

specified in this parameter when an encoder with

distance-coded reference marks (linear scale/rotary

encoder) (detection circuit C) is used, P/S 5325

may be issued at reference position establishment

time.

[Data type] Word axis

[Unit of data] Detection unit × 100,000,000

[Valid data range] -20 to 20

This parameter is used when the distance from the encoder origin to

the reference position is not within the range set in parameter No.

1883.

In parameter Nos. 1883 and 1884, set the distance from the origin of

an encoder with absolute addressing reference marks (linear

scale/rotary encoder)/encoder with distance-coded reference marks

(linear scale/rotary encoder) (detection circuit C) to the reference

position. The distance from the origin of an encoder to the reference

position can be found by the following expression:

Distance from the origin of an encoder to the reference position

= No.1884 × 100,000,000 + No.1883

The origin of an encoder represents the point where mark 1 and mark

2 match. Usually, this point is a virtual point not physically existing

on the encoder. (See the figure below.)

Set a positive value if the reference position is located in the +

direction when viewed from the encoder point. Set a negative value if

the reference position is located in the - direction when viewed from

the encoder point.
