B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 159 -

1885 Maximum allowable value for total travel during torque control

[Data type] Word axis

[Unit of data] Detection unit

[Valid data range] 0 to 32767

This parameter sets the maximum allowable value for the total travel

(error counter value) for an axis placed under torque control, as

specified by the axis control command of the PMC axis control

function. If the total travel exceeds the parameter-set value while

torque control is applied, a servo alarm (No.423) is generated.

NOTE

This parameter is enabled when bit 4 (TQF) of

parameter No.1803 is 0 (follow-up is not performed

during torque control).

1886 Positional deviation when torque control is canceled

[Data type] Word axis

[Unit of data] Detection unit

[Valid data range] 0 to 32767

This parameter sets the positional deviation used when torque control,

performed for an axis according to the axis control command of the

PMC axis control function, is canceled and position control is

resumed. After the positional deviation has fallen to the parameter-set

value, switching to position control is performed.

NOTE

This parameter is enabled when bit 4 (TQF) of

parameter No.1803 is 0 (follow-up is not performed

during torque control).

1890 Servo motor speed for detection

NOTE

When this parameter is set, the power must be

turned off before operation is continued.

[Data type] Word

[Unit of data] min

-1

[Valid data range] 0 to 8000

The servo motor speed of each axis is monitored and a motor speed

detection signal is output indicating whether the speed of each axis

exceeds the value set in this parameter (set in the Y address specified

in parameter No.1891)

NOTE

No motor speed detection signals are output when

the servo/spindle motor speed detection function is

not used or 0 is set in this parameter.
