4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 530 -

G8C Advanced preview control for the axes controlled by the PMC is:

0 : Disabled.

1 : Enabled.

NOTE

This parameter is valid for an axis for which bit 7

(NAHx) of parameter No.1819 is set to 0.

G8R Advanced preview control over axes controlled by the PMC is:

0 : Enabled for cutting feed (disabled for rapid traverse).

1 : Enabled for both cutting feed and rapid traverse.

NOTE

This parameter is valid for an axis for which bit 7

(NAHx) of parameter No.1819 is set to 0.

DSL If the selection of an axis is changed when PMC axis selection is

disabled:

0 : P/S alarm No.139 is issued.

1 : The change is valid, and no alarm is issued for an unspecified

system.

NCI In axis control by the PMC, a position check at the time of

deceleration is:

0 : Performed.

1 : Not performed.

NDI In axis control by the PMC, when diameter programming is specified

for a PMC-controlled axis:

0 : The amount of travel and feedrate are each specified with a

radius.

1 : The amount of travel and feedrate are each specified with a

diameter.

NOTE

NDI is valid for an axis for which diameter

programming is specified (bit 3 (DIAx) of parameter

No. 1006 is set to 1) when bit 1 (CDI) of parameter

No. 8005 is set to 0.

#7 #6 #5 #4 #3 #2 #1 #0

8005 MFD IGE IFV PVP DRR R10 CDI EDC

[Data type] Bit

EDC In axis control by the PMC, an external deceleration signal is:

0 : Disabled.

1 : Enabled.
