Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 309

Parameter manual

Page of 782

/ 782

B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 297 -

[Setting method] First, select servo axes which perform interpolation with the Cs

contouring axis. (Up to five axes can be selected.)

When there is no servo axis for interpolation with the Cs contouring

axis, set the parameters No. 3900, No. 3910, No. 3920, No. 3930, and

No. 3940 to 0 to terminate parameter setting.

When there are servo axes for interpolation with the Cs contouring

axis, the parameters must be set according to the procedure below for

each axis.

(1) Set the number of a servo axis (1 to 8) for interpolation with the

Cs contouring axis in parameters 39n0 (n = 0, 1, 2, 3, and 4).

(2) Set loop gain values of the servo axis specified in (1) above

which is used when the Cs contouring axis is controlled in

parameters No. 39n1, No. 39n2, No. 39n3, and No. 39n4. (There

are four stages for main gears used.)

(3) When the number of specified servo axes is less than 5, set the

remaining parameter No. 39n0 to 0 to terminate parameter

setting.

When the number of a Cs contouring axis is set to parameter No. 39n0,

the parameter is assumed to be set to 0.

NOTE

1 In general, it is difficult to set a high loop gain for a

spindle motor axis when compared with a servo

axis. These parameters are provided so that, by

changing the loop gain of a servo axis that requires

interpolation with the Cs contour axis, interpolation

control can be exercised correctly between the Cs

axis and servo axis while the spindle exercises Cs

contour control.

2 The loop gain of the servo axis is changed using

the parameter settings made for a spindle gear

selected at the time of conversion from the spindle

mode to the Cs contour control mode.

In normal use, it is unlikely that the gear of the

spindle is switched during Cs contour control.

However, note that if the gear of the spindle is

changed during Cs contour control, the loop gain of

the servo axis is not changed.

3 Even when multiple Cs axes are used with one

path (bit 7 (CSS) of parameter No. 3704 = 1), these

parameters are shared.
