4.DESCRIPTION OF PARAMETERS B-63530EN/03
- 554 -
Synchronous error limit of each axis (synchronous/composite control)
8181
[Data type] 2-word axis
[Unit of data] Detection unit
[Valid data range] 0 to 32767
When the synchronous error detected (Bit 1 (SERx) of parameter
No.8162 is set to 1), this parameter specifies the limit of the difference
between the position deviation of the slave axis and that of the master
axis. Set this parameter to the slave axis.
Display of the synchronous error of an axis (synchronous/composite
control)
8182
[Data type] 2-word axis
[Unit of data] Detection unit
When the synchronization deviation is detected (Bit 1 (SERx) of
parameter No.8162 is set to 1), this parameter specifies the difference
between the position deviation of the slave axis and that of the master
axis. (The value is used for diagnosis.)
The difference between the position deviation is:
Position deviation of the master axis ± Position deviation of the slave axis
↑
Plus for a mirror-image synchronous
control command
Minus for a simple synchronous control
command
NOTE
Parameter No.8182 is only for display. It cannot be
set value.
