B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 759 -

CRS In tool center point control for 5-axis machining, when the deviation

from the path during movement at the specified cutting feedrate or

rapid traverse rate is determined to exceed the limit:

0 : The setting of bit 7 (SUP) of parameter No. 19696 is followed.

1 : The feedrate or rapid traverse rate is controlled so that the limit

of the deviation from the path set in the parameter for the cutting

feed or rapid traverse is not exceeded.

When this parameter is set to 1:

In the rapid traverse mode, the rapid traverse rate is decreased so that

the deviation from the path does not exceed the limit specified in

parameter No. 19751.

In the cutting feed mode, the cutting feedrate is decreased so that the

deviation from the path does not exceed the limit specified in

parameter No. 19752.

19747

Rotation angle at the start of the tool center point control mode for 5-axis

machining applied to the first rotary axis

[Data type] 2-word

[Unit of data]

Increment system IS-B IS-C Unit

Unit of data 0.001 0.0001 deg

[Valid data range] -99999999 to 99999999

Set a rotation angle at the start of the tool center point control mode

for 5-axis machining applied to the first rotary axis. This parameter is

valid when bit 0 (SAC) of parameter No. 19746 is set to 1.

19748

Rotation angle at the start of the tool center point control mode for 5-axis

machining applied to the second rotary axis

[Data type] 2-word

[Unit of data]

Increment system IS-B IS-C Unit

Unit of data 0.001 0.0001 deg

[Valid data range] -99999999 to 99999999

Set a rotation angle at the start of the tool center point control mode

for 5-axis machining applied to the second rotary axis. This parameter

is valid when bit 0 (SAC) of parameter No. 19746 is set to 1.
