B-65270EN/05 3. αiS/αiF/βiS SERIES PARAMETER ADJUSTMENT

- 101 -

3.3.5 Vibration during Travel

Vibration is generated during travel by various causes. So, a most

appropriate method must be selected after observing the vibration

status carefully.

Vibration occurs especially

during acceleration/

deceleration.

<1> Is an auxiliary function set to increase the oscillation limit for the velocity loop gain?

Machine with high rigidity: Velocity loop proportional high-speed processing function

Machine with low rigidity: Acceleration feedback function

<2> Vibration frequency?

Low frequency

<3> Velocity loop oscillates. Is an auxiliary function

used to suppress vibration?

TCMD filter (function 1)

Several tens of

hertz or higher

<4> Is the standard value set for the current loop

gain?

<8> Response to vibration components from the

command side. Decrease the velocity

feed-forward coefficient (200 or less).

<9> Set 16 ms for the fine acceleration/

deceleration function. (Function 5)

<11> The position gain may be too large for the set

velocity loop gain. When the velocity loop gain

is not yet adjusted, follow the description in

Subsec. 3.3.1 to set the velocity loop gain to

70% of the oscillation limit.

<12> For PI function, are effective results produced

by decreasing the velocity loop integral gain by

about 2/3?

<13> Decrease the position gain.

<6> Vibration may be due to machine torsion. Is an

auxiliary function used to suppress vibration?

Dual position feedback (function 2)

Vibration-damping control (function 3)

Machine velocity feedback (function 4)

TCMD filter (function 1)

bout several tens Hertz

ith separate detector

<7> Decrease the position gain.

Use of I-P function may produce effective results.

After checking for a figure error during high-speed

cutting, decrease the position gain, or set I-P function.

<5> Decrease the velocity loop gain.
