5.DETAILS OF PARAMETERS B-65270EN/05

- 378 -

ABG0(#3) 1: When an unexpected disturbance torque is detected, a threshold

is set separately for cutting and rapid traverse.

[Reference item] Subsection 4.12.2

[Related parameters] 1997 (15i), 2104 (16i etc.), 1765 (15i), 2142 (16i etc.)

RISCMC (#5) When a RISC processor is used:

0: The response to a positioning command is the same as before.

1: The response to a positioning command is improved.

[Reference item] Subsection 4.6.3

P2EX (#6) The velocity loop proportional gain (PK2V) format is:

0: Standard format. (See Item (5) of Subsec. 4.14.1.)

1: Converted format.

[Reference item] Supplement 4 of Subsection 2.1.5

#7 #6 #5 #4 #3 #2 #1 #0

1741 (FS15i)

CPEE RNLV CROFS

2201 (FS30i, 16i)

CROFS (#0) The function for obtaining current offsets upon an emergency stop is:

0: Not used.

1: Used .

[Reference item] Section 4.13

RNLV (#1) Specifies the detection level for the feedback mismatch alarm as

follows:

0: 600 min

-1

1: 1000 min

-1

CPEE (#6) The actual current display peak hold function is:

0: Not used

1: Used

#7 #6 #5 #4 #3 #2 #1 #0

1742 (FS15i)

DUAL OVS1 PIAL VGCCR FADCH

2202 (FS30i, 16i)

FADCH (#0) The cutting/rapid FAD switching function is:

0: Not used.

1: Used .

[Reference item] Section 4.3 and Subsection 4.8.3

[Related parameters] 1702 (15i), 2109 (16i etc.), 1766 (15i), 2143 (16i etc.), 1951 (15i),

2007 (16i etc.)

VGCCR (#1) The cutting/rapid velocity loop gain switching function is:

0: Not used.

1: Used .

[Reference item] Section 4.3 and Subection 4.5.5

[Related parameters] 1858 (15i), 2046 (16i etc.), 1700 (15i), 2107 (16i etc.)
