D.PARAMETERS RELATED TO HIGH-SPEED AND HIGH-PRECISION OPERATIONS APPENDIX B-65270EN/05

- 458 -

Parameter

No.

Standard setting

value

Description

8480#4 0 To be set to the standard setting value.

8480#5 0 To be set to the standard setting value.

8480#6 0 To be set to the standard setting value.

19501#6 1/0

To be set to 1 if a function of changing the time constant for bell-shaped

acc./dec. before interpolation is to be used.

19504#0 1 Bell-shaped rapid traverse acc./dec. is used.

19520

mm / inch

10000/3937

Reference speed (mm/min / inch/min) for a function of changing the time

constant for bell-shaped acc./dec. before interpolation

19600#0 0/1

Scaling is performed on the CNC side or, as 5-axis control mode, on the RISC

side. (An option is necessary.)

19600#1 0/1

Programmable mirror image is performed on the CNC side or, as 5-axis control

mode, on the RISC side. (An option is necessary.)

19600#2 0/1

Rotary dynamic fixture offset is performed on the CNC side or, as 5-axis control

mode, on the RISC side. (An option is necessary.)

19600#3 0/1

Coordinate rotation is performed on the CNC side or, as 5-axis control mode, on

the RISC side. (An option is necessary.)

19600#4 0/1

Three-dimensional coordinate conversion is performed on the CNC side or, as

5-axis control mode, on the RISC side. (An option is necessary.)

19600#5 0/1

Cutter compensation C is performed on the CNC side or, as 5-axis control mode,

on the RISC side. (An option is necessary.)
