B-65270EN/05 4.SERVO FUNCTION DETAILS

- 305 -

<2>-a When using A06B-6057-H620 (digital check board), set the

DIP switches on the check board as follows:

To measure an odd-numbered axis:

xis 2

xis 1

Outputs for PIO-48W PC-Card Output to Analog Spindle

Input from JA8A

Data T

e Settin

Axis4 Axis3 Axis2 Axis1

1: High 0: Low

CNB

16B-2300-

xxxx xxxx

CN12 CN11

CN13

CNSCNB CNB CNB

CNA1

0001 1010

DIP switch

06B-6057-H620

AXIS2: 1 (torque) AXIS1: 10 (phase)

To measure an even-numbered axis:

xis 2

xis 1

AXIS2: 3 (torque) AXIS1: 11 (phase)

<2>-b When using A06B-6057-H630 (one-piece analog/digital type),

set up the 7-segment LED digits on the check board as shown

below:

* Letter X stands for an axis

number specified in parameter

No. 1023.

CH1

Phase

CH2

Tor

<3> To measure the activating phase angle, set the following

parameter.

1726 (FS15i)

Parameter for internal data measurement

2115 (FS16i)

Series 9096: 1328 (for both odd- and even-numbered axes)

Series 90B0, 90B1, 90B6, 90B5:

704 for odd-numbered axis and 2752 for

even-numbered axis

Steps <2> and <3> enable CH0 and CH1 of the SD software to be

used to measure the motor activating phase angle (CH0) and torque

command (CH1).
