2. SETTING αiS/αiF/βiS SERIES SERVO PARAMETERS B-65270EN/05

- 10 -

2.1.3 Servo Parameter Initialization Procedure

(1) Preparation

Switch on the NC in an emergency stop state.

Enable parameter writing (PWE = 1).

Initialize servo parameters on the servo setting screen.

For a Power Mate i with no CRT, specify a value for an item number

on the servo setting screen. See Fig. 2.1.3.

To display the servo setting screen, follow the procedure below, using

the key on the NC.

- Series 15i

Press the

SYSTEM

key several times, and the servo setting screen will

appear.

- Series30i,31i,32i,16i,18i,21i,20i,0i

→

[SYSTEM]

→

[ ]

→

[SV-PRM]

If no servo screen appears, set the following parameter as shown, and

switch the NC off and on again.

#7 #6 #5 #4 #3 #2 #1 #0

3111 SVS

SVS (#0) 1: Displays the servo screen.

When the following screen appears, move the cursor to the item you

want to specify, and enter the value directly.

Servo set

INITIAL SET BITS

Motor ID No.

AMR

CMR

Feed gear N

(N/M) M

Direction Set

Velocity Pulse No.

Position Pulse No.

Ref. counter

X axis

00001010

00000000

100

111

8192

12500

10000

01000 N0000

Z axis

00001010

00000000

100

111

8192

12500

10000

Power Mate

No.2000

No.2020

No.2001

No.1820

No.2084

No.2085

No.2022

No.2023

No.2024

No.1821

Fig. 2.1.3 Servo setting screen Correspondence of Power Mate i
