B-65270EN/05 APPENDIX C.FUNCTION-SPECIFIC SERVO PARAMETERS

- 439 -

: Parameters set up automatically or cleared at initialization

Parenthesized parameters : Common parameters that are also used for other functions

Parameter number

FS15i FS30i,16i,etc.

Meaning

1956#1 2012#1 Machine speed feedback function

1981 2088 Machine speed feedback gain

→ 4.5.8

[Contour error suppression functions]

[Feed-forward functions]

1808#3 2003#3 PI control

1883#1 2005#1 Feed-forward function

1961 2068 Feed-forward coefficient

→ 4.6.1 to 4.6.3

1962 2069 Velocity feed-forward coefficient

→ 4.6.1 to 4.6.3

1985 2092 Advanced preview feed-forward coefficient

→ 4.6.2

1959#5 2017#5 1: The response of feed-forward is improved when RISC is used.

1740#5 2200#5

1: The response of the position command is improved when RISC is

used.

→ 4.6.3

1800#3 1800#3 Enables feed-forward in rapid traverse.

→ 4.3

→ 4.8.3

1988 2095 Feed-forward timing adjustment coefficient

2808 2395

Feed-forward timing adjustment coefficient (for use when FAD is

enabled)

→ 4.6.5

(1742#0) (2202#0)

Switches the feed-forward coefficient between cutting and rapid

traverse.

(This parameter is also used for the cutting/rapid traverse-specific fine

acc./dec. function.)

2602#3 2214#4

Switches the feed-forward coefficient between cutting and rapid

traverse.

(This function is independent of fine acc./dec..)

1767 2144 Position feed-forward coefficient for cutting

1768 2145 Velocity feed-forward coefficient for cutting

(1985) (2092) Position feed-forward coefficient for rapid traverse

(1962) (2069) Velocity feed-forward coefficient for rapid traverse

→ 4.3

→ 4.6.4

→ 4.8.3

[Backlash acceleration functions]

1808#5 2003#5 Backlash acceleration function

1860 2048 Backlash acceleration amount

1964 2071 Period during which backlash acceleration remains effective

(1725) (2114) Acceleration amount override

(2751) (2338) Limit of acceleration amount

(1987) (2094) Backlash acceleration amount (for reverse from negative to positive

direction)

(2753) (2340) Acceleration amount override (for reverse from negative to positive

direction)

(2754) (2341) Limit of acceleration amount (for reverse from negative to positive

direction)

1953#7 2009#7 Backlash acceleration stop

1975 2082 Timing at which the backlash acceleration is stopped

1953#6 2009#6

1: Enables the backlash acceleration function during cutting feed

only.

→ 4.6.6

1851 1851 Backlash compensation

1884#0 2006#0 1: Does not reflect the backlash compensation in positions.

→ 4.6.6 to 4.6.7

1957#6

(1808#5)

2015#6

(2003#5)

Two-stage backlash acceleration function

(The backlash acceleration function is also enabled.)

→ 4.6.7
