B-65270EN/05 4.SERVO FUNCTION DETAILS

- 263 -

(Example of setting for a rotary motor)

- Suppose that the estimated disturbance value at 1000 min

-1

is 1

[Ap] (the maximum amplifier current value is 40 [Ap]).

Dynamic friction compensation coefficient = 1/40 × 440 = 11

These portions represent

disturbances due to dynamic

friction. An adjustment is made

to eliminate these portions.

Read value

(A)

The effect of dynamic friction is

reduced, and stable estimated

disturbance values are

obtained.

Dynamic friction compensation

before setting

Dynamic friction compensation

after setting

(ii) Method of setting a dynamic friction as "portion

proportional to velocity + constant portion" and imposing a

limit

If the compensation value for stop time to low-velocity

movement is insufficient in adjustment of (i), set a dynamic

friction compensation value in the stop state. If the

compensation value for high-speed movement is excessive,

a limit is imposed on the compensation value.

No.2758(Series 15

)

No.2345(Series 16

and so

on)

Compensation value in the

sto

time

No.2759(Series 15

)

No.2346(Series 16

and

so on)

Com

ensation limit value

No.1727(Series 15

)

No.2116(Series 16

and

so on)

Dynamic friction

com

ensation coefficient

Velocity

Dynamic friction compensation value

1000min

Set a compensation value in the stop time and

a compensation limit value in addition to a

com

ensation value at 1000 min

-1
