4.SERVO FUNCTION DETAILS B-65270EN/05

- 240 -

(5) Separate detector-based dummy feedback

The separate detector-based dummy feedback function is intended to

ignore alarms for an axis when the separate detector has been

disconnected from the axis temporarily. Set the following bit.

#7 #6 #5 #4 #3 #2 #1 #0

1745 (FS15i)

FULDMY

2205 (FS30i, 16i)

FULDMY (#2) Specifies whether to enable the separate detector-based dummy

feedback function as follows:

1: To enable

0: To disable

NOTE

The relationships of this function with the built-in

Pulsecoder-based serial feedback dummy function

are as follows:

• When only the built-in Pulsecoder-based serial

feedback dummy function is enabled:

Alarms related to the built-in Pulsecoder and

amplifier are ignored.

• When only the separate detector-based dummy

feed-back function is enabled:

Alarms related to the separate detector are

ignored.

• When both the functions are enabled:

Alarms related to the built-in Pulsecoder,

separate detector, and amplifier are ignored.

4.9.2 How to Use the Dummy Feedback Functions for a Multiaxis

Servo Amplifiers When an Axis Is Not in Use

If an axis connected to a multiaxis amplifier is not in use, it is

necessary to set the dummy function bit described in Subsec. 4.9.1 and

connect a dummy connector to the amplifier.

Information about dummy connector Location

Jumper between pins 11 and 12. JFx
