13.FUNCTIONS TO SIMPLIFY PROGRAMMING PROGRAMMING B-63324EN/03
- 326 -
CAUTION
For inch inputs, an F command with no decimal point
is assumed to have a decimal point in between its
second and third places as counted from the lowest
place. Note that the settings of RFA = 0 and RFE = 0
can produce the following example.
Example) When F1234 is issued, F12.34 (inch/min)
is assumed, resulting in F12.00 (inch/min).
Example
Z-axis feedrate 1000 mm/min
Spindle speed 1000 min
-1
Thread lead 1.0 mm
<Programming for feed per minute>
G94 ; Specify a feed-per-minute
command.
G00 X120.0 Y100.0 ; Positioning
G84.3 Z-100.0 R-20.0 F1000 ; Rigid tapping
<Programming for feed per revolution>
G95 ; Specify a feed-per-revolution command.
G00 X120.0 Y100.0 ; Positioning
G84.3 Z-100.0 R-20.0 F1.0 ;Rigid tapping
CAUTION
Ensure that the tapper thread pitch matches a
programmed pitch (F, S). Otherwise, the tool or a
part being machined may be destroyed.
