B-63324EN/03 APPENDIX F.ALARM LIST
- 793 -
Number Message Contents
PS0449 ILLEGAL TOOL LIFE DATA Tool life management data is damaged for some reason.
Reload the tool group and the corresponding tool data by
G10 L3; or MDI input.
PS0450 IN PMC AXIS MODE The PMC axis control mode, the CNC issued a move
instruction for the PMC axis.
A move instruction can be issued on one axis from only
either the PMC or the CNC.
This alarm is generated when a move instruction is issued
from both.
This alarm can be suppressed by setting NPA of parameter
No. 2405#5 to "1".
PS0470
G40.1 ‘G42.1 PARAMETER MISS
The normal line direction control axes parameter settings
are erroneous.
- Set the normal line direction control axis setting in NDC
parameter No. 1006#6. Only one axis can be set to "1"; this
is not possible for multiple axes.
- Set the axis for which NDC parameter No. 1006#6 is set to
"1" to axis of rotation (ROT parameter No. 1006#6=1, and
parameter No. 1022=2).
- Set the feedrate when rotation of the normal line direction
control axis is set to parameter No. 1472 within the range 1
to 5000 degrees/min.
PS0472 ILL-COMMAND IN G81.1 MODE Either G81.1 was instructed again while in the chopping
mode, or a move instruction was issued to the chopping
axis.
To change the chopping conditions, cancel G80 and
specify G81.1 again.
PS0508 DUPLICATE M-CODE (INDEX TABLE
REVERSING)
A function to which the same code as this M code is set
exists.
(indexing of index table)
PS0509 DUPLICATE M-CODE (SPOS AXIS
ORIENTATION)
A function to which the same code as this M code is set
exists.
(spindle positioning, orientation)
PS0510 DUPLICATE M-CODE (SPOS AXIS
POSITIONING)
A function to which the same code as this M code is set
exists.
(spindle positioning, positioning)
PS0511 DUPLICATE M-CODE (SPOS AXIS
RELEASE)
A function to which the same code as this M code is set
exists.
(spindle positioning, mode cancel)
PS0531 ILLEGAL USE OF DECIMAL POINT
(F-CODE)
When the feedrate instruction contains valid data below the
decimal point, the alarm is set and the F code contains
valid data below the decimal point.
PS0532 ILLEGAL USE OF DECIMAL POINT
(E-CODE)
When the feedrate instruction contains valid data below the
decimal point, the alarm is set and the E code contains
valid data below the decimal point.
PS0533 ADDRESS F UNDERFLOW (G95) The feedrate for the hole drilling axis calculated from the F
and S codes is too slow in the feed per single rotation mode
(G95).
PS0534 ADDRESS F OVERFLOW (G95) The feedrate for the hole drilling axis calculated from the F
and S codes is too fast in the feed per single rotation mode
(G95).
PS0535 ADDRESS E UNDERFLOW (G95) The feedrate for the hole drilling axis calculated from the E
and S codes is too slow in the feed per single rotation mode
(G95).
PS0536 ADDRESS E OVERFLOW (G95) The feedrate for the hole drilling axis calculated from the E
and S codes is too fast in the feed per single rotation mode
(G95).
PS0537 ADDRESS F UNDERFLOW
(OVERRIDE)
The speed obtained by applying override to the F
instruction is too slow.
PS0538 ADDRESS F OVERFLOW
(OVERRIDE)
The speed obtained by applying override to the F
instruction is too fast.
PS0539 ADDRESS E UNDERFLOW
(OVERRIDE)
The speed obtained by applying override to the E
instruction is too slow.
