4. PROGRAM FORMAT

Function Explanation

Tool nose radius

compensation

(G40, G41, G42)

G41

G42

G40

G40 ; Programmed path

G41 ; Left of programmed path

G42 ; Right of programmed path

Cutter compensation B

(G39 to G42)

Cutter compensation C

(G40 to G42)

G41

G42

G40

G40 ; Programmed path

G41 ; Left of programmed path

G42 ; Right of programmed path

Three–dimensional tool

compensation

(G40, G41)

Programmed path

Path after three–dimensional tool

compensation

Three–dimensional tool com-

pensation vector

G41

G40

Vx =

i ⋅ r

Vy =

j ⋅ r

Vz =

k ⋅ r

+ j

+ k

The three–dimensional tool compensation vector is

obtained from the following expressions:

(Vector component along the

Xp–axis)

(Vector component along the

Yp–axis)

(Vector component along the

Zp–axis)

In the above expressions, i, j, and k are the values

specified in addresses I, J, and K in the block. r is

the offset value corresponding to the specified offset

number. p is the value obtained from the following

expression:

Normal direction control

(G40.1, G41.1 G42.1)

Normal direction

(proceeding direction)

Programmed

path

C axis

Tool

C axis

Tool
