14. HISTORY FUNCTION

789

The records of some alarms, messages, and operations can be referenced.

14.1 Alarm History

Alarms generated in the NC are recorded. The latest 25 alarms generated

are recorded. The 26th and former alarms are deleted.

D Display of alarm history screen

(1) Press

MESSAGE

key .

(2) Press soft key [HISTRY] and an alarm history screen is displayed.

(3) Other pages are displayed by

PAGE

key.

ALARM HISTORY O1234 N12345

01/04/18 20:56:26

506 OVERTRAVEL : +X

01/04/18 19:58:11

000 TURN OFF POWER

01/04/18 19:52:45

000 TURN OFF POWER

01/04/18 19:48:43

300 APC ALARM : X–AXIS ZERO RETURN REQUEST

01/04/18 18:10:10

507 OVERTRAVEL : +B

[ ALARM ][ MSG ][ HISTRY ][ ][ (OPRT) ]

D Clearing alarm history

(1) Press soft key [(OPRT)].

(2) Press soft key [CLEAR], then the alarm history is cleared.

The clearing of the alarm history can be disabled by setting

PRM3110#2(AHC).

D Alarm display

When an external alarm (ALM1000–1999) or a macro alarm (ALM3000–

3999) is output, the alarm history function can record the alarm message.

If recording of the message is not set or if no message is input, only an

external alarm or macro alarm is displayed.

D Parameter

#6 #5 #4 #3 #2 #1 #0

3112

EAH

#3 (EAH) The alarm history function:

0 : Does not record the messages output with external

alarms or macro alarms.

1 : Records the messages output with external alarms or

macro alarms.
