7. PARAMETERS

335

04003 Position coder, orientation

#0 PCMGSL : The system of the orientation is position

coder system (0)/magnetic sensor system

(1)

#1 PCCNCT : A motor’s built-in sensor is not used (0)/

used (1).

#2 DIRCT1 : The direction of rotation at the spindle

orientation

#3 DIRCT2 : The direction of rotation at the spindle

orientation

#4 PCTYPE : Position coder signal setting (See the

table below.)

#6 PCPL1 : Position coder signal setting (See the

table below.)

#7 PCPL2 : Position coder signal setting (See the

table below.)

PCPL2

PCPL1

PCTYPE

256 λ/rev

Built-in

sensor

65 φ

High-

resolution

magnetic

pulse coder

Position coder,

high-resolution

position coder

Remarks

0 0 1 128 λ/rev ––

0 1 0 512 λ/rev 130 φ –

01 164λ/rev ––

10 0 – 195 φ –

1 1 0 384 λ/rev 97.5 φ –

DIRECT 2

Direction of rotation

immediately before

spindle orientation

Direction of rotation

immediately before

spindle orientation

The counter-clockwise

in view of the motor

shaft

The clockwise in view

of the motor shaft

DIRECT 1

04004 Detector selection

#0 HRPC : A high-resolution position coder is not used

(0)/used (1).

#1 SPDBIS : A separate built-in sensor is not used (0)/

used (1).

#2 EXTRF : The external one-rotation signal is not

used (0)/used (1).

#3 REFTYP : The external one-rotation signal is

detected on its rising edge (0)/falling edge

(1).

#4 BISGAN : A standard built-in sensor is used (0)/a

built-in sensor with a non-standard gain is

used (1).

PRM

4003#1=1
