13. DIAGNOSIS INFORMATION

771

Alarm

detail

No.

ActionCause

Param-

eter No.

1853 2185 A negative value or a value

greater than the setting of

PRM2023 is set.

Set a positive value less

than the setting of PRM

2023.

2243 2224#5 PRM2224#5 is set to 1 (to ig-

nore a machine distortion

compensation parameter er-

ror), and the nano interpola-

tion command is specified.

Make one of the two set-

tings.

3423 2342 A negative value or a value

greater than 100 is set.

Change the setting to a posi-

tive value not greater than

100.

3433 2343 A value not within a range of

–180 to 180 is set.

Set a value within a range of

–180 to 180.

8213 1821 A non–positive value is set

in the reference counter size

parameter.

Set a positive value in this

parameter.

8254

8255

8256

1825 The internal value of the

position gain overflowed.

Use the position gain in-

crease function.

10016

10019

2200bit0 The internal value of the pa-

rameter related to crash

detection overflowed.

Do not use the crash detec-

tion function. (Set bit 0 to 1.)

10024

10025

An overflow occurred in an

internal calculation on the

separate serial link proces-

sing level.

Switch to software of 90B0

series D edition and later.

10033 2004 The control period setting is

invalid.

This alarm is issued when

the control period is auto-

matically modified.

Modify this parameter re-

lated to interrupt period set-

ting.

10043 1815#1

2010#2

When a linear motor is used,

the closed loop is set.

Switch to software support-

ing the closed loop for a lin-

ear motor.

10053 2018#0 When a linear motor is used,

the scale reverse connec-

tion bit is set.

The scale reverse connec-

tion bit cannot be used when

a linear motor is used.

10062 2209#4 The amplifier in use does not

support the HC alarm circuit

avoidance function.

If you continue using the cur-

rently used amplifier, set the

function bit indicated to the

left to 0.

If you want to use the HC

alarm avoidance function,

prepare an amplifier that

supports the function.

10072 2007#6 The customer board function

and FAD are set at the same

time.

Turn off one of the two func-

tions.

10082 2213#6 The improved cutting/rapid

traverse–specific position

gain switch function is not

supported by the NC.

Disable this function.
