19. MAINTENANCE FUNCTION

953

D Storing colors (color palette values)

A specified color palette value can be stored.

STORE COLOR3COLOR1CALL COLOR2

1. Select a desired storage area by pressing the [COLOR1], [COLOR2],

or [COLOR3] operation soft key.

(If the [COLOR1], [COLOR2], and [COLOR3] operation soft keys are

not displayed, press the rightmost soft key.)

COLOR1

COLOR2

COLOR3

Standard color data parameters (6561 to 6595)

Internal RAM

2. Press the [STORE] operation soft key. The following operation soft

keys appear.

EXECCAN

3. To store the current color palette values in the selected area, press the

[EXEC] operation soft key. To cancel the storage, press the [CAN]

operation soft key or the leftmost key.

D Calling colors (color palette values)

STORE COLOR3COLOR1CALL COLOR2

1. Select a color palette storage area by pressing the [COLOR1],

[COLOR2], or [COLOR3] operation soft key.

(If the [COLOR1], [COLOR2], and [COLOR3] operation soft keys are

not displayed, press the rightmost soft key.)

2. Press the [CALL] operation soft key. The following operation soft keys

appear.

EXECCAN

3. To call the color palette values from the selected area, press the [EXEC]

operation soft key. If no color palette value is stored, this step cannot

be executed.

To stop calling, press the [CAN] operation soft key or the leftmost key.

D Notes

(1) At power–up, the color scheme of the screen is determined by the

setting in the COLOR1 area (parameters). If no data is stored in the

COLOR1 area, the last color scheme before power–down is applied.

(2) The standard color data specified in PRM6561–6595 must not be

changed by direct MDI key input. When changing the parameter data,

set and store the new data on the color setting screen.

(3) When a wrong value is specified in a standard color data parameter, the

screen may not be displayed. If this occurs, turn the power on again,

while pressing the

DELETE

and

RESET

keys. This clears the whole stored

color scheme and restores the FANUC standard color scheme instead.

Be very careful when performing this operation, as all memory contents

such as parameters and programs are lost.
