8.2 Alarms Displayed on the PMC Screen

514

Alarm number Contents

Faulty location/

corrective action

WN23 TASK COUNT

OVER

Change the TASK

COUNT in the link control

statement to 16 or less.

(To change the task count,

modify the link control

statement, build file, and

the configuration of the

files to be linked.)

When a PMC C

language board is used,

the number of user tasks

exceeds 16.

WN24 TASK ENTRY

ADDR ERROR

Change the GDT table in

the build file to 32 (20H) to

95 (5FH).

When a PMC C

language board is used,

the user task entry

address selector is out of

range.

WN25 DATA SEG

ENTRY ERROR

Change the DATA SEG-

MENT GDT ENTRY value

in the link control state-

ment and the GDT table in

the build file to 32 (20H) to

95 (5FH).

When a PMC C

language board is used,

the data segment entry

address is out of range.

WN26 USER TASK

PRIORITY ERROR

Change the TASK LEVEL

of each task in the link

control statement to a val-

ue from 10 to 99 or –1.

(Note that –1 can be spe-

cified for the TASK LEVEL

of only one task, including

the third Ladder level).

When a PMC C

language board is used,

the priority of the user

task is out of range.

WN27 CODE SEG

TYPE ERROR

Change the value of the

code segment according

to the segment setting in

the link control statement

and build file.

When a PMC C

language board is used,

the code segment type is

invalid. The setting of

the RENA–MESEG code

segment in the bind

control file is wrong.

WN28 DATA SEG TYPE

ERROR

Change the value of the

data segment according

to the segment setting in

the link control statement

and build file.

When a PMC C

language board is used,

the data segment type is

invalid. The setting of

the RENA–MESEG data

segment in the bind

control file is wrong.

WN29 COMMON MEM

SEG TYPE ERROR

Change the value accord-

ing to the segment setting

in the link control state-

ment and build file.

When a PMC C

language board is used,

the shared memory

segment type is invalid.

The setting of the

RENAMESEG segment

in the shared memory

bind control file is wrong.
