8. ALARM LIST

465

No. ContentsMessage

TOO MANY AXES

COMMANDED

(M series)

An attempt was made to move the machine

along the axes, but the number of the axes

exceeded the specified number of axes

controlled simultaneously. Modify the pro-

gram.

015

TOO MANY AXES

COMMANDED

(T series)

An attempt has been made to move the tool

along more than the maximum number of

simultaneously controlled axes. Alterna-

tively, no axis movement command or an

axis movement command for two or more

axes has been specified in the block con-

taining the command for skip using the

torque limit signal (G31). The command

must be accompanied with an axis move-

ment command for a single axis, in the

same block.

020 OVER TOLERANCE OF

RADIUS

In circular interpolation (G02 or G03), differ-

ence of the distance between the start point

and the center of an arc and that between

the end point and the center of the arc ex-

ceeded the value specified in PRM3410.

021 ILLEGAL PLANE AXIS

COMMANDED

An axis not included in the selected plane

(by using G17, G18, G19) was commanded

in circular interpolation (G02, G03). Modify

the program.

022 NO CIRCLE RADIUS The command for circular interpolation

(G02, G03) lacks arc radius R or coordinate

I, J, or K of the distance between the start

point to the center of the arc.

023 ILLEGAL RADIUS

COMMAND

(T series)

In circular interpolation by radius designa-

tion, negative value was commanded for

address R. Modify the program.

025 CANNOT COMMAND F0 IN

G02/G03

(M series)

F0 (rapid traverse) was instructed by F1

–digit column feed in circular interpolation

(G02, G03). Modify the program.

027 NO AXES COMMANDED IN

G43/G44

(M series)

No axis is specified in G43 and G44 blocks

for the tool length offset type C.

Offset is not canceled but another axis is

offset for the tool length offset type C.

Modify the program.

028 ILLEGAL PLANE SELECT In the plane selection command (G17,

G18, G19), two or more axes in the same

direction are commanded. Modify the pro-

gram.

ILLEGAL OFFSET VALUE

(M series)

The offset values specified by H code is too

large. Modify the program.

029

ILLEGAL OFFSET VALUE

(T series)

The offset values specified by T code is too

large. Modify the program.

030

ILLEGAL OFFSET NUMBER

(M series)

The offset number specified by D/H code

for tool length offset, cutter compensation,

or three–dimensional tool offset is too

large. Alternatively, the number of an addi-

tional workpiece coordinate system speci-

fied with the P code is too large. Modify the

program.

ILLEGAL OFFSET NUMBER

(T series)

The offset number in T function specified

for tool offset is tool large. Modify the pro-

gram.
