Series 16i/18i/21i/160i/180i/210i/160is/180is/210is - Model B Operation and maintenance handbook Page 309

Operation and maintenance handbook

Page of 992

/ 992

7.2 Parameter List

276

16) For feedrate

01401

Feedrate

#0 RPD : Manual rapid traverse before the completion of

return to reference position is disable (0)/

enable (1)

#1 LRP : Positioning (G00) is nonlinear (0)/linear (1).

#2 JZR : Manual return to the reference position at Jog

feedrate is not performed (0)/performed (1)

#4 RF0 : When cutting feedrate override is 0% during

rapid traverse, the machine tool does not stop

moving (0)/stops moving (1)

#5 TDR : Dry run during thread cutting and canned cycle

(G74, G84) is enable (0)/disable (1)

#6 RDR : Dry run for rapid traverse command is, disable

(0)/enable (1)

T series

01402 Manual feed per revolution

#0 NPC : The feed per rotation command is ineffective

when a position coder is not provided (0)/

provided (1)

#1 JOV : Job override is, enabled(0)/disabled (tied to

100%)(1)

#3 OV2 : The secondary feedrate override value is 1%

(0)/0.01% (1).

#4 JRV : Manual continuous feed (jog feed) is

performed at feed per minute (0)/at feed per

rotation (1)

T series

01403 Units used for feed per minute, threading retract T series

#0 MIF : The unit of F for feed per minute is [mm/min]

(0)/0.001 [mm/min] (1).

#7 RTV : Overriding during threading retraction is

enabled (0)/disabled (1).
