Series 16i/18i/21i/160i/180i/210i/160is/180is/210is - Model B Operation and maintenance handbook Page 381

Operation and maintenance handbook
7
7.2 Parameter List
348
04257 Limit value for the motor output specifications
04258 Base speed
04259 Magnetic flux weakening start velocity
04260 Current loop proportional gain during normal
operation
04261 Current loop integral gain during normal
operation
04262 Zero point of current loop integral gain
04263 Velocity factor of current loop proportional gain
04264 Current conversion constant
04265 Secondary current factor for excitation current
04266 Current expectation constant
04267 Slip constant
04268 Compensation constant for high–speed rotation
slip
04269 Compensation constant for voltage applied to
motor in the dead zone
04270 Electromotive force compensation constant
04271 Phase compensation constant of electromotive
force
04272 Compensation velocity factor for electromotive
force
04273 Time constant for changing the torque
04274 Displayed value of load meter for maximum
output
04275 Maximum output zero speed
04276 Secondary current factor in rigid tapping
04277 Constant for compensating for the phase of
the electromotive force at deceleration
04278 Time constant of the speed detection filter
04279 Reserved
04280 Time constant of voltage filter for electromotive
force compensation
04281 Spindle load monitor torque constant (for
low–speed characteristic on the MAIN side)
