4. PROGRAM FORMAT

110

Program format T series M series

Hole position data

Drilling data

Number of repeat

Drilling mode

G73 X__Y__Z__P__Q__R__F__K__ ;

G74 X__Y__Z__P__Q__R__F__K__ ;

G76 X__Y__Z__P__Q__R__F__K__ ;

G81 X__Y__Z__P__Q__R__F__K__ ;

G82 X__Y__Z__P__Q__R__F__K__ ;

G83 X__Y__Z__P__Q__R__F__K__ ;

G84 X__Y__Z__P__Q__R__F__K__ ;

G85 X__Y__Z__P__Q__R__F__K__ ;

G86 X__Y__Z__P__Q__R__F__K__ ;

G87 X__Y__Z__P__Q__R__F__K__ ;

G88 X__Y__Z__P__Q__R__F__K__ ;

G89 X__Y__Z__P__Q__R__F__K__ ;

G80 ; Cancel

Gjj X__Y__Z__R__Q__P__F__K__ ;

Item Address Explanation

Drilling mode GVV G73, G74, G76, G80 to G89

Hole position data X, Y Specifies the hole position by an in-

cremental or absolute value.

Drilling data Z Specifies the distance from point R to

the bottom of the hole.

R Specifies the distance from the initial

level to point R.

Q Specifies each cut-in value with G73

and G83 or the shift value with G76

and G87. (Always specified with an

incremental value.)

P Specifies the dwell time at the bottom

of the hole.

F Specifies the feed rate.

Number of repeats K Specifies the number of repeats for a

series of operation 1 to 6.

G75 I_J_K_X (Z)_R_F_P_L_ ;

G77 I_J_K_X (Z)_R_F_P_L_ ;

G78 I_J_K_X_R_F_P_L_ ;

G79 I_J_K_X (Z)_R_F_P_L_ ;

I: Depth-of-cut 1 (A sign in the command speci-

fies the direction of cutting.)

J: Depth-of-cut 2 ( A sign in the command speci-

fies the direction of cutting.)

K: Total depth of cut

X (Z): Range of grinding

(A sign in the command specifies the direction

of grinding.)

R: Feedrate for I and J

F: Feedrate for X (Z) (G75/G77/G79)/Feedrate (G78)

P: Dwell time

L: Grinding-wheel wear compensation (only for

continuous dressing)

Contents Summary of Series 16i/18i/21i/160i/180i/210i/160is/180is/210is - Model B Operation and maintenance handbook
