16. DIGITAL SERVO

849

#6 #5 #4 #3 #2 #1 #0

3006

GDC

GDC As the deceleration signal for reference position return:

0 : X009/X007 is used.

1 : G196/G1196 is used. (X009/X007 is disabled.)

7181

First withdrawal distance in butt–type reference position setting

Axis type

When the butt–type reference position setting function is used,

this parameter sets a distance on an axis, along which

withdrawal is performed after the mechanical stopper is hit

(distance from the mechanical stopper to the withdrawal point).

Set the same direction as the direction set for PRM1006#5(ZMIx).

If the opposite direction is set, the cycle operation will not start.

7182

Second withdrawal distance in butt–type reference position setting

Axis type

When the butt–type reference position setting function is used,

this parameter sets a distance on an axis, along which

withdrawal is performed after the mechanical stopper is hit

(distance from the mechanical stopper to the withdrawal point).

Set the same direction as the direction set for PRM1006#5(ZMIx).

If the opposite direction is set, the cycle operation will not start.

7183

First butting feedrate in butt–type reference position setting

Axis type

When the butt–type reference position setting function is used,

this parameter sets the feedrate first used to hit the stopper on

an axis.

7184

Second butting feedrate in butt–type reference position setting

Axis type

When the butt–type reference position setting function is used,

this parameter sets the feedrate used to hit the stopper on an

axis for a second time.

Withdrawal feedrate (common to the first and second butting

operations) in butt–type reference position setting)

7185

Axis type

When the butt–type reference position setting function is used,

this parameter sets the feedrate used for withdrawal along an

axis after the mechanical stopper has been hit.

7186

Torque limit value in butt–type reference position setting (%)

Axis type

This parameter sets a torque limit value in butt–type reference

position setting.

When 0 is set in this parameter, 100% is assumed.
