9.2 I/O Signal List

578

Symbol

series

AddressSignal name

MHPCC HPCC mode signal F066#6 – f

MI1 to MI8 Mirror image signal G106 f f

MINC Incremental feed select

check signal

F003#0 f f

MINP External program input start

signal

G058#0 f f

MIX1 to MIX8 Composite control axis

selection signals

G128 F –

MJ JOG feed select check

signal

F003#2 f f

MLK All–axis machine lock

signal

G044#1 f f

MLK1 to MLK8 Each–axis machine lock

signal

G108 f f

MLKO Software operator’s panel

signal(MLK)

F075#4 f f

MMDI Manual data input select

check signal

F003#3 f f

MMEM Automatic operation select

check signal

F003#5 f f

MMI1 to MMI8 Mirror image check signal F108 f f

MMLK All–axis machine lock

check signal

F004#1 f f

MMOD Check mode signal G067#2 f –

MNCHG Inversion inhibition signal F091#1 f –

MORA1A F046#6 f f

MORA1B

Signal for completion of

spindle orientation with a

F050#6 f f

MORA1C

spindle orientation with a

magnetic sensor

F169#6 f f

MORA1D

(serial spindle)

F267#6 f f

MORA2A F046#7 f f

MORA2B

Signal for approximate

spindle orientation with a

F050#7 f f

MORA2C

spindle orientation with a

magnetic sensor

F169#7 f f

MORA2D

(serial spindle)

F267#7 f f

MORCMA G073#0 f f

MORCMB

Command for spindle

G077#0 f f

MORCMC

orientation with a magnetic

sensor (serial spindle)

G207#0 f f

MORCMD

sensor (serial spindle)

G269#0 f f

MP1, MP2 Manual handle feed

amount selection signal

(incremental feed signal)

G019#4,

f f

MP1O Software operator’s panel

signal (MP1)

F076#0 f f

MP2O Software operator’s panel

signal (MP2)

F076#1 f f
