8. ALARM LIST

481

No. ContentsMessage

241 ILLEGAL FORMAT IN

G02.2/G03.2

(M series)

The end point, I, J, K, or R is missing from

a command for involute interpolation.

242 ILLEGAL COMMAND IN

G02.2/G03.2

(M series)

An invalid value has been specified for in-

volute interpolation.

S The start or end point is within the basic

circle.

S I, J, K, or R is set to 0.

S The number of rotations between the

start of the involute curve and the start

or end point exceeds 100.

243 OVER TOLERANCE OF

END POINT

(M series)

The end point is not on the involute curve

which includes the start point and thus falls

outside the range specified with PRM5610.

244 P/S ALARM

(T series)

In the skip function activated by the torque

limit signal, the number of accumulated er-

roneous pulses exceed 32767 before the

signal was input. Therefore, the pulses

cannot be corrected with one distribution.

Change the conditions, such as feed rates

along axes and torque limit, and try again.

245 T–CODE NOT ALOWEE IN

THIS BLOCK

(T series)

One of the G codes, G50, G10, and G04,

which cannot be specified in the same

block as a T code, was specified with a T

code.

246 ENCODE PROGRAM

NUMBER ERROR

During read of an encrypted program, an

attempt was made to store the program

with a number exceeding the protection

range.

(See PRM3222 and 3223.)

247 ILLEGAL CODE USED

FOR OUTPUT

When an encrypted program is output, EIA

is set for the punch code. Specify ISO.

250 Z AXIS WRONG COMMAND

(ATC)

(M series)

Movement along the Z–axis is specified in

a block specifying a tool change command

(M06T_). (Only for ROBODRILL)

251 ATC ERROR

(M series)

This alarm is issued in the following cases:

S An M06T_ command contains an unus-

able T code.

S An M06 command has been specified

when the Z machine coordi nate is posi-

tive.

S The parameter for the current tool num-

ber (PRM7810) is set to 0.

S An M06 command has been specified

in canned cycle mode.

S A reference position return command

(G27 to G44) and M06 command have

been specified in the same block.

S An M06 command has been specified

in tool compensation mode (G41 to

G44).

S An M06 command has been specified

without performing reference position

return after power–on or the release of

emergency stop.

S The machine lock signal or Z–axis ig-

nore signal has been turned on during

tool exchange.

S A pry alarm has been detected during

tool exchange.

Refer to DGN530 to determine the cause.

(Only for ROBODRILL)
