10. PMC

665

10.2.2.4 Trace screen (TRACE)

Record the signal status to the trace memory when the specified signal is

changed.

(1) Trace parameter screen (TRCPRM)

T.DISP

[][][][][]

EXEC

PMC SIGNAL TRACE

MONIT RUN

TRACE MODE :

(0:1BYTE/1:2BYTE/2:WORD)

1ST TRACE ADDRESS CONDITION

ADDRESS TYPE : (0:PMC/1:PHY)

ADDRESS :

MASK DATA

2ND TRACE ADDRESS CONDITION

ADDRESS TYPE : (0:PMC/1:PHY)

ADDRESS :

MASK DATA :

(a) TRACE MODE: Select the trace mode.

0= 1 byte address signal trace

1= Independent 2 byte address signal trace

2= Continuous 2 byte address signal trace

(b) ADDRESS TYPE: 0= Set the trace address by PMC address

1= Set the trace address by physical

address (Using mainly by C language)

(d) MASK DATA : Specify the trace bit by hexadecimal code.

For example, set the “E1” when trace the bit

7, 6, 5 and 0. Not execute the tracing when

the bit 4, 3, 2 and 1 is changed, but, the signal

status should recorded at tracing time.

(e.g) #7 #6 #5 #4 #3 #2 #1 #0

11100001:E1

Ơ Correspond table between binary and hexadecimal code ơ

0000

: 0

0001

0010

: 2

0011

: 3

0100

: 4

0101

: 5

0110

: 6

0111

: 7

1000

: 8

1001

: 9

1010

: A

1011

: B

1100

: C

1101

1110

: E

1111

: F

(e) [EXEC] soft key :

Start of tracing.

Clear the trace memory and trace memory contents are update

when the specified signal are changed from previous ones.

The trace memory are always maintained up to the previous

results for 256 bytes from the latest ones regardless of the time

lapse.

(2 byte tracing = 128 times.)

(f) [T.DISP] soft key : Display of trace memory contents.
